Image Processing

Image Sensor

1'' GS-CMOS

Shutter Mode

Single shutter / double shutters / three shutters

Electronic Shutter Speed

1/50 s–1/100000 s (auto/manual)

Exposure Mode

Full auto/customized range/customized

Iris Control

Fixed iris/manual iris/auto iris/P iris

Image Resolution

4096 × 2820 (OSD black strip excluded)

Video Resolution

(4096 × 2820)/QFHD (3840 × 2160)/1080P (1920 × 1080)/UXGA (1600 × 1200)/720P (1280 × 720)

Video Frame Rate

Maximum 50 fps; main stream (4096 × 2820@25 fps), sub stream (1600 × 1200@25 fps)

Video Bit Rate

H.264: 32 kbps–32768 kbps
H.265: 32 kbps–32768 kbps
MJPEG: 512 kbps–32768 kbps

Video Compression

H.265; H.264M; H.264H; H.264B; MJPEG

Picture Encoding Format

JPEG

WDR

64dB

White Balance

Auto/home/office/night/custom color temperature

Noise Reduction

2DNR/3DNR

Day/Night

Supports ICR auto switch: IR cut-off filter (IRCF) with polarizing filter is used during daytime, and IR will not be filtered during nighttime

HLC (Highlight Compensation)

Yes

Bad Pixel Correction

Yes

Edge Enhancement

Yes

Illuminator Number

8 illuminators (850nm IR illuminators, brightness adjustable)

Illumination Distance

50 m (164.04 ft)

Function

Composite Image

Supports composing 1, 2, 3, or 4 pictures

Trigger Mode

Video detection/radar/coil

OSD Overlay

Time, location (video channel location), lane (number, direction), and plate number

Storage

FTP, TF card (maximum 256GB@Class10)

Alarm Event

Storage full, storage error, external alarm, no storage card, license plate blacklist, abnormal device attitude, illegal access, network disconnection, and IP conflict

Automatic Network Replenishment (ANR)

Platform, FTP

Image Tampering Prevention

Yes. Watermark and verification are available for videos and pictures

Positioning Function

GPS/BeiDou

Time Synchronization

NTP/GPS/BeiDou

Security

Authorized username and password, MAC address binding, HTTPS encryption, and network access control

Auto Registration

Yes

Intelligence

Target Detection

Motor vehicle, non-motor vehicle

Face Detection

Detects driver and front-seat passenger of motor vehicle, and non-motor vehicle driver; extracts face image

Vehicle Plate Recognition

Recognizes license plates in Russian

Vehicle Type Recognition

Vehicle head mode: Coach bus, minibus, SUV, MPV, pickup, heavy truck, medium truck, van, light truck
Vehicle tail mode: SUV, car, van, coach bus, pickup, cargo truck, mini truck, tank truck, mixer truck

Vehicle Color Recognition

White, pink, black, red, yellow, gray, blue, green, amber, purple, brown, silver gray (color recognition is not supported during nighttime)

Motor Vehicle Violation Snapshot

ANPR mode: Wrong-way driving, overspeed, underspeed, disobey lane direction sign, cross white solid line, cross yellow solid line, illegal lane change, video speed measurement

Non-motor Vehicle Violation Snapshot

Captures traffic violations including carrying passenger, not wearing helmet, wrong-way driving, and occupying motorway

Traffic Flow Detection

Statistics of vehicle flow, queue length, average speed, lane occupancy, and more; statistics can be exported in Excel

Traffic Event Detection

Detects illegal parking and wrong-way driving of motor vehicles and traffic congestion

Video Metadata

Motor vehicle: License plate, vehicle type, vehicle color, license plate color, vehicle logo, and more (color recognition is not supported during nighttime)
Non-motor vehicle: Type (two-wheelers, three-wheelers), carrying passenger or not, wearing a helmet or not, and color

Port

Iris Control

1, connects to auto iris or P iris

Focus Control

1, connects to motorized vari-focal lens

Frequency Source Sync

1, supports synchronizing the camera with mains electricity

Peripheral Light

7, optocoupler signal output (can be configured as flashing light or LED strobe sync output interface, frequency adjustable)

Network

2 RJ-45 Ethernet ports, 10/100/1000M network transmission

USB

2 USB 3.0 ports

GPS

1 GPS/BeiDou port

Storage

1, supports maximum 256GB TF card local storage

RS-485

2, connects to signal detector, vehicle detector, flashing light, continuous light, and more

RS-232

4 RS-232 ports. 3 for radar connection, and 1 for serial port debugging

I/O

4, capture signal input of I/O trigger, sharing with alarm in port

Alarm Input

4, share with I/O port

Alarm Output

2, AO1 relay output and AO2 optocoupler output, can be configured as alarm output or wiper output as needed

Audio In

1, 3.5 mm (0.14'') jack

Audio Out

1, 3.5 mm (0.14'') jack

Power Output

12V DC±10% voltage output, ≤1.5A current output

General

Lens

16 mm–40 mm IR lens

Power Supply

100V AC–240V AC (50Hz/60Hz)

Power Consumption

≤20W

Operating Temperature

−40 °C to +65 °C (−40 °F to +149 °F)

Operating Humidity

10%–90%

Protection Grade

IP66

Dimensions

554.0 mm × 204.2 mm × 209.6 mm (21.81'' × 8.04'' × 8.25'') (L × W × H)

Net Weight

4.6 kg (10.14 lb)

Gross Weight

6.6 kg (14.55 lb)

Installation

Universal joint installation

Power Adapter

Standard
