Camera

Image Sensor

Two 1/2.8”2Megapixel progressive scan CMOS

Effective Pixels

1920(H) x 1080(V)

RAM/ROM

4096MB/4096MB

Scanning System

Progressive

Minimum Illumination

0.003Lux/F1.4 (Color,1/3s,30IRE)

0.03Lux/F1.4 (Color,1/30s,30IRE)

0Lux/F1.4(IR on)

IR Distance

Distance up to 40m(131ft)

IR On/Off Control

Auto/ Manual

IR LEDs

2

Lens

Lens Type

Fixed

Mount Type

Board-in

Focal Length

2.8mm (3.6mm, 6mm)

Max. Aperture

F1.4

Angle of View

H: 111° (86°,54°), V:62° (46°,30°),

Optical Zoom

N/A

Focus Control

Fixed

Close Focus Distance

0.7m (1.2m,2.4m)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm

29m(95ft)

16m(52ft)

6m(20ft)

3m(10ft)

3.6 mm

43m(141ft)

17m(56ft)

9m(30ft)

4m(13ft)


6 mm

50m(164ft)

20m(66ft)

10m(33ft)

5m(16ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

Pan:0˚~355˚; Tilt:0˚~64˚; Rotation:0˚~355˚

Artificial Intelligence

Behavior analysis

Fall detection, Strand detection, People approach, People NO. error detection,Violence detection

General Intelligence

Event Trigger

Motion detection, Video tampering, Scene changing,

Network disconnection, Ip address conflict, Illegal

access, Storage anomaly

General Intelligence

Tripwire, Intrusion, Object Abandoned/Missing, Heat Map

Video

Compression

H.265/H.264H/MJPEG(Sub Stream)

Smart Codec

Support H.265+/H.264+

Streaming Capability

3 Streams

Resolution

1080P(1920×1080)/ 1.3M(1280x960)/ 720P(1280x720)/ D1(704×576/704x480) / VGA(640x480)/ CIF(352×288/342x240)

Frame Rate

Main Stream: 2MP (1~25/30fps)

Sub Stream 1: D1 (1 ~ 25/30fps)

Sub Stream 2: 2MP (1~25fps/30fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.264: 1792~ 9216Kbps

H.265: 512~ 5632Kbps

Day/Night

Auto(ICR) / Color / B/W

BLC Mode

BLC / HLC / WDR(120dB)

White Balance

Auto/Natural/Street Lamp/Outdoor/Manual

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Electronic Image Stabilization (EIS)

N/A

Smart IR

Support

Defog

N/A

Digital Zoom

16x

Flip

N/A

Mirror

N/A

Privacy Masking

Off / On (4 Area, Rectangle)

Audio

Compression

G.711a/ G.711Mu/ AAC/ G.726

Network

Ethernet

RJ-45 (100/1000Base-T)

Protocol

HTTP;HTTPs; TCP;ARP;RTSP; RTP;UDP;RTCP;SMTP;

FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;

NTP; Bonjour; IEEE 802.1x;Multicast; ICMP; IGMP;SNMP;TLS

Interoperability

ONVIF Profile G&S, API

Streaming Method

Unicast / Multicast

Max. User Access

10 Users/20 Users

Edge Storage

NAS

Local PC for instant recording

Mirco SD card 256GB

Web Viewer

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS, DMSS

Smart Phone

IOS, Android

Certifications

Certifications

CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

Interface

Video Interface

1 port (For Adjustment Only)

Audio Interface

1/1 channel In/Out (RCA), Built-in Mic

RS485

1 port

Alarm

3 channel In: 5mA 5VDC

2 channel Out: 300mA 12VDC

Electrical

Power Supply

DC12V±30%, PoE (IEEE 802.3af)(Class 0)

Power Consumption

< 8.77W

Environmental

Operating Conditions

-40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Storage Conditions

-40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Ingress Protection

IP67

Vandal Resistance

N/A

Construction

Casing

Metal

Dimensions

176.9mmx230.9mmx50.4mm (6.97"x9.09"x1.99")

Net Weight

1.9kg (4.2lb)

Gross Weight

2.3kg (5.1lb)
