Camera

Image Sensor

1/2.7” 5Megapixel progressive scan CMOS

Effective Pixels

2592(H)x1944(V)

RAM/ROM

512MB/32MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

0.006Lux/F2.0( Color,1/3s,30IRE)

0.02Lux/F2.0( Color,1/30s,30IRE)

0Lux/F2.0(IR on)

IR Distance

Distance up to 10m(33ft)

IR On/Off Control

Auto/ Manual

IR LEDs

3

Lens

Lens Type

Fixed

Mount Type

Board-in

Focal Length

1.4mm

Max. Aperture

F2.0

Angle of View

H: 180˚, V:180˚

Optical Zoom

N/A

Aperture type

Fixed

Close Focus Distance

N/A

DORI Distance

Detect

Observe

Recognize

Identify

28m(92ft)

11m(36ft)

6m(19ft)

3m(9ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

N/A

Intelligence

IVS

Tripwire, Intrusion

Advanced Intelligent Functions

Heat Map

Video

Compression

H.265/H.264/H.264H/MJPEG(Sub Stream)

Smart Code

Support H.265+/H.264+

Streaming Capability

3 Streams

Resolution

5M(2582×1944)/ 3M(2048x1536)/ UXGA(1600x1200)/ 1.3M(1280x960)/ 1080P(1920x1080)/ 720P(1280X720)/ D1(704×576/VGA(640X480)/ CIF(352×288)

Frame Rate

Main Stream: 5M(1~25fps)

Sub Stream: D1(1 ~ 25/30fps)

Third Stream: D1(1 ~ 10/17fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.265: 3Kbps~ 40960Kbps

H.264: 3Kbps~ 40960Kbps

Day/Night

Auto(ICR) / Color / B/W

BLC Mode

BLC / HLC / WDR(120dB)

White Balance

Auto/Natural/Street Lamp/Outdoor/Manual

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detetion

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Electronic Image Stabilization(EIS)

N/A

Smart IR

Support

Defog

N/A

Digital Zoom

16x

Flip

N/A

Mirror

N/A

Privacy Masking

Off / On (4 Area, Rectangle)

Audio

Compression

G.711a/G.711Mu/PCM

Network

Ethernet

RJ-45 (100/1000Base-T)

Protocol

HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; SNMP; QoS; UPnP; NTP; RTMP

Interoperability

ONVIF, CGI, API

Streaming Method

Unicast / Multicast

Max. User Access

10 Users/20 Users

Edge Storage

NAS

Local PC for instant recording

Mirco SD card 128GB

Web Viewer

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS, DMSS

Smart Phone

IOS, Android

Certifications

Certifications

CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

Interface

Video Interface

N/A

Audio Interface

1/1 channel In/Out, 1 Built-in Mic

RS485

N/A

Alarm

1 channel In: 5mA 5VDC

1 channel Out: 300mA 12VDC

Electrical

Power Supply

DC12V, PoE (802.3af)(Class 0)

Power Consumption

DC12V: 2.7W 8.2W(IR on)

PoE: 3.3W 10.1W(IR on)

Environmental

Operating Conditions

-10° C ~ +50° C (14° F ~ +122° F) / Less than 95% RH

Strorage Conditions

-10° C ~ +50° C (14° F ~ +122° F) / Less than 95% RH

Ingress Protection

N/A

Vandal Resistance

N/A

Construction

Casing

Metal+Plastic

Dimensions

Φ126.2mm×44.7mm(Φ4.9”×1.8”)

Net Weight

0.28kg(0.6lb)

Gross Weight

0.41kg(0.9lb)
