Camera

Image Sensor

1/1.7” CMOS

Effective Pixels

4000 (H) × 3000 (V)

ROM

4 GB

RAM

4 GB

IR LEDs

3 (IR LEDs)

Electronic Shutter Speed

1/3 s-1/100000 s (Auto/Manual)

Min. Illumination

0.001 Lux/F2.0 (Colour, 1/3 s, 30 IRE)
0.01 Lux/F2.0 (Colour,, 1/30 s, 30 IRE)
0 Lux/F2.0 (IR on)

IR Distance

10 m (32.8 ft)

Scan

Progressive

Noise Reduction

3D DNR

WDR

120dB

S/N Ratio

49.7dB

Gain control

Auto/Manual

White Balance

Auto/Natural/street lamp/outdoor/manual/regional Custom

Lens

Focal Length

1.85 mm

Mount Type

M12

Max. Aperture

F2.0

Aperture Type

Fixed aperture

Lens Type

Fixed focal

Field of View

Horizontal: 185°; Vertical: 180°,360° (ceiling mounting)

DORI Distance

Detect

Observe

Recognize

Identify

40.0 m (131.3 ft)

16.0 m

(52.6 ft)

8.0 m

(26.3 ft)

4.0 m

(13.1 ft)

Audio

Audio Input

1 channel (RCA port),1 build in MIC

Audio Output

1 channel (RCA port)

Audio Encoding

G.711A, G.711Mu, G726, AAC

Video

Video Encoding

H.265, H.264, H.264H, H.264B, MJPEG

Streaming Capability

3 Streams

Video Frame Rate

50Hz Main Stream (4000 × 3000@25fps), sub Stream (704 × 576@25fps), third Stream (704 × 576@25fps)

60Hz Stream (4000 × 3000@30fps), sub Stream (704 × 480@30fps), third Stream (704 × 480@30fps)

Fisheye:

1O (4000 x 3000)

1P (4096 x 1024)

2P (2432 x 2432)

1R (1216 x 1216)

2R (2432 x2432)

4R (2432 x 2432)

1O + 3R (2432 x 2432)

Resolution

4000 × 3000, 2880 × 2880, 2880 × 2160, 2048 × 1536 (3M), 1280 × 960 (1.3M), (704 × 576/704 × 480) D1, (352 × 288/352 × 240) CIF

Video Quality Adjustment

Multiple compression levels up to 6 levels

Bit Rate Control

CBR/VBR

Region of Interest

Yes (4 areas)

Smart IR

Yes (Adjust by user)

Language

English, Italian, Spanish, Russian, French, German, Portuguese, Polish, Korean, Persian, Czech, Dutch, Arabic, European Spanish

Alarm

Alarm Input

2 channels (Wet contact, and it supports max potential 3V-5V)

Alarm Output

2 channels (Dry contact, and it supports max potential 30V)

Function

SD Card

Yes

Storage

FTP, Micro SD card (256 G)

Max User

20 (Total bandwidth: 240 M)

Browser

IE: IE11, IE10, IE9
Google of high version: 48.0.2564.116
Firefox of high version: 48.0.2
Non-plug edge: 42.17134.1.0

Privacy Masking

4 areas

Smart event

IVS Analyze

Intrusion, tripwire

Heat Map

Yes

Event Trigger

Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access, Storage anomaly

Professional, intelligent

People Counting

People counting in 4 areas, number of people threshold alarm, 4 queue management, stranding alarm, number of people alarm, number of people heat map, average stranding heat map, track map and export (Report max range is 1 week.)

Network and port

Ethernet

RJ-45(10/100/1000Base-T)

Network Protocol

HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/v6, SNMP, QoS, UPnP, NTP

Interoperability

ONVIF (Profile S/Profile G), GB/T28181, CGI

General

Power Supply

12V DC /POE

Power Consumption

Basic power consumption: 6.2W (12V DC), 9.2W (POE)
Max power consumption: (ICR switch, and IR full intensity): 9.2W (12V DC), 12.9W (POE)

Operating Temperature

-30°C to +50°C (-22°F to +113°F)

Operating Humidity

≤95%

StrorageTemperature

-30°C to +70°C (-22°F to +158°F)

Strorage Humidity

≤95%

Protection Grade

IP67, IK10

Enclosure

Metal + Plastic

Dimensions

59.8 mm × Φ149.8 mm (2.35'' × Φ5.9'')

Net Weight

0.77 kg(1.70 lb)

Gross Weight

1.16 kg(2.56 lb)
