Camera

Image Sensor

Panoramic: 1/2.8" CMOS
Detail: 1/2.8" CMOS

Pixel

Panoramic: 2MP
Detail: 2MP

Max. Resolution

Panoramic: 1920 (H) × 1080 (V)
Detail: 1920 (H) × 1080 (V)

ROM

8 GB

RAM

2 GB

Electronic Shutter Speed

Panoramic: 1/3 s–1/100000 s
Detail: 1/1 s–1/100000 s

Scanning System

Progressive

Min. Illumination

Panoramic:
Color: 0.005lux@F1.6
B/W: 0.0005lux@F1.6
Detail:
Color: 0.005lux@F1.6
B/W: 0.0005lux@F1.6
0Lux (IR light on)

Illumination Distance

Panoramic (white light): 30 m (98.43 ft)
Detail (IR light): 100 m (328.08 ft)

Illuminator On/Off Control

Panoramic: SmartIR/Manual/Off
Detail: Zoom Prio/Manual/SmartIR/Off

Illuminator Number

Panoramic: 4 white lights
Detail: 4 IR lights

Lens

Focal Length

Panoramic: 6 mm (0.24")
Detail: 4.8 mm–120 mm (0.19"–4.72")

Max. Aperture

Panoramic: F1.6
Detail: F1.6–F3.5

Field of View

Panoramic: H: 53.7; V: 28.7; D: 61.8
Detail: H: 59.6°–4.8°; V: 35.4°–2.7°; D: 66.5°–5.5°

Optical Zoom

25x

Focus Control

Auto/Semi-Auto/Manual

Close Focus Distance

Panoramic: 0.2 m (0.66 ft)
Detail: 0.1 m–1.5 m (0.33 ft–4.92 ft)

Iris Control

Panoramic: Fixed
Detail: Auto

DORI Distance

Detect

Observe

Recognize

Identify

Panoramic:
88.3 m (289.70 ft)
Detail:
1613.8 m (5294.62 ft)

Panoramic:
35.3 m (115.81 ft)
Detail:
645.5 m (2117.78 ft)

Panoramic:
17.7 m (58.07 ft)
Detail:
322.8 m (1059.06 ft)

Panoramic:
8.8 m (28.87 ft)
Detail:
161.4 m (529.53 ft)

PTZ

Pan/Tilt Range

Panoramic:
Pan: 0°–360° endless; Tilt: 0°–30°
Detail:
Pan: 0°–250°; Tilt: -10°–90°

Manual Control Speed

Panoramic:
Pan: 7°/s–117°/s; Tilt: 3°/s–25°/s
Detail:
Pan: 1.8°/s–131°/s; Tilt: 0.5°/s–65°/s

Preset Speed

Panoramic:
Pan: 242°/s; Tilt: 58°/s
Detail:
Pan: 430°/s; Tilt: 243°/s

Presets

300

Tour

8 (up to 32 presets per tour)

Pattern

5

Scan

5

Power-off Memory

Support

Idle Motion

Preset/Tour/Pattern/Scanning

Protocol

DH-SD
Pelco-P/D (auto recognition)

Artificial Intelligence

Perimeter Protection

Tripwire, intrusion, abandoned object, and missing object . Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc.

Smart Tracking

Support

Video

Compression

H.265; H.264BaselineProfile; H.264MainProfile; H.264HighProfile; M-JPEG; smart H.265; smart H.264

Streaming Capability

3 streams

Resolution

Panoramic:
1080P (1920 × 1080); 960P (1280 × 960);

720P (1280 × 720); D1 (704 × 576/704 × 480);

CIF (352 × 288/352 × 240)
Detail:
1080P (1920 × 1080); 960P (1280 × 960);

720P (1280 × 720); D1 (704 × 576/704 × 480);

CIF (352 × 288/352 × 240)

Frame Rate

Main stream: 1080P/1.3M/720P (1–50/60 fps)

Sub stream 1: D1/CIF (1–25/30 fps)
Sub stream 2: 1080P/1.3M/720P/CIF (1–25/30 fps)

Bit Rate Control

Variable/Constant

Bit Rate

H.264: 1792 Kbps–9216 Kbps
H.265: 512 Kbps–5632 Kbps

Day/Night

Panoramic: Auto (ICR)
Detail: Auto (ICR)

BLC

Support

WDR

Panoramic: 120dB
Detail: 120dB

HLC

Support

White Balance

Auto; Indoor; Outdoor; Tracking; Manual; Sodium lamp; Natural light; Street lamp

Gain Control

Auto; Manual

Noise Reduction

2D/3D

Motion Detection

Support

Region of Interest (RoI)

Support

Image Stabilization

Electronic

Defog

Digital

Digital Zoom

16x

Flip

0°/180°

Audio

Compression

G.711a; G.711mu; G.726; AAC; MPEG2-Layer2; G.722.1; G.729

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMP; DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; SNMPv1/v2c/v3 (MIB-2); RTCP

Interoperability

ONVIF Profile S&G&T; CGI

Streaming Method

Unicast/Multicast

User/Host

20 (Total bandwidth 64M)

Storage

P2P; FTP; Micro SD (256G)

Browser

IE7 and later versions
Chrome 45 and earlier versions
Firefox 52 and earlier versions
Safari 12 and earlier versions

Management Software

SmartPSS; DSS; NVR

Certifications

Certifications

CE: EN55032/EN55024/EN50130-4

FCC: Part15 subpartB,ANSI C63.4-2014

Port

Audio Input

1 (LINE IN bare wire)

Audio Output

1 (LINE OUT bare wire)

Alarm I/O

2/1
Digital input: 0–5V DC

Power

Power Supply

DC36V/2.23A±25%
Hi-PoE

Power Consumption

Basic: 21W
Max.: 40W (PTZ, zoom, focus, IR light, white light, and smart plan enabled)

Environment

Operating Temperature

-40°C to +70°C (-40°F to +158°F)

Operating Humidity

≤95%

Protection

IP67; TVS 8000V lightning protection; surge protection

Structure

Dimensions

385 mm × Φ277 mm (15.16" × Φ10.91")

Net Weight

9 kg (19.84 lb)

Gross Weight

13.8 kg (30.42 lb)
