Camera |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor |
1/1.8” STARVIS™ CMOS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pixels |
8 Megapixels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Resolution |
3840(H) x 2160(V) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System |
Progressive |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed |
1/1s~1/30,000s |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Minimum Illumination |
Color: 0.002Lux@F1.4; B/W: 0.0002Lux@F1.4; 0Lux@F1.4 (IR on) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR Distance |
500 m (1640.42 ft) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR On/Off Control |
Auto/Manual |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR LEDs |
10 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Wiper |
Support |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length |
5.6mm~223mm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Aperture |
F1.4~ F4.8 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Angle of View |
H: 63.9° ~ 2.0°; V: 37.2° ~ 1.2° ; D: 71.2° ~ 2.4° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Optical Zoom |
40x |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focus Control |
Auto/Manual |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Iris Control |
Auto (P-Iris) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance |
0.1 m–1 m (0.33 ft–3.28 ft) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Detect |
Observe |
Recognize |
Identify |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||
4400m(14435ft) |
1740 m |
880 m |
440 m |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PTZ |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pan/Tilt Range |
Pan: 0° ~ 360° endless; Tilt: -30° ~ 90°,auto flip 180° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Manual Control Speed |
Pan: 0.1° ~240° /s; Tilt: 0.1° ~100° /s |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Preset Speed |
Pan: 240° /s; Tilt: 120° /s |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Presets |
300 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Tour |
8 (up to 32 presets per tour) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Speed Adjustment |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power-off Memory |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Idle Motion |
Preset; Tour; Pattern; Scanning |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protocol |
DH-SD, Pelco-P/D (Auto recognition) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Artificial Intelligence |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Auto Tracking |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recogntion |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Perimeter Protection |
Tripwire, Intrusion. Support alarm triggering by target types(human and vehicle) Filtering out false alarms caused by animals, rustling leaves, bright lights, etc |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Metadata |
Support human body, human face, motor vehicle and non-motor vehicle image capture and attributes extraction |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General Intelligence |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Event Trigger |
Motion detection, Video tampering , Scene changing, Network disconnection, IP address conflict, Illegal Access, Storage anomaly |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General Intelligence |
Object Abandoned/Missing |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Compression |
H.265+; H.265; H.264+; H.264/MJPEG(Sub Stream) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Streaming Capability |
3 Streams |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution |
4K(3840x2160); 1080P(1920×1080); 1.3M(1280x 960); 720P(1280×720); D1(704×576/ 704×480); CIF(352×288/352×240) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Frame Rate |
Main stream: 4K(1~25/30fps), 1080P/1.3M/720P (1~25/30fps) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Sub stream1: D1/CIF(1 ~ 25/30fps) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Sub stream2: 1080P/1.3M/720P(1 ~ 25/30fps) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate Control |
CBR/VBR |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate |
H.265/H.264: 512K ~ 8192Kbps |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night |
Auto(ICR) / Color / B/W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Backlight Compensation |
BLC / HLC / WDR(120dB) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
White Balance |
Auto, ATW, Indoor, Outdoor, Manual |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gain Control |
Auto / Manual |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction |
Ultra DNR (2D/3D) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motion Detection |
Support |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Region of Interest |
Support |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Stabilization |
Electronic |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Defog |
Optical |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Digital Zoom |
16x |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Flip |
180° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Privacy Masking |
Up to 24 areas |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Compression |
G.711a; G.711mu; PCM; G.726/AAC; G722.1; G.729; MPEG2-Layer2 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Ethernet |
RJ-45 (10Base-T/100Base-TX) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protocol |
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, RTCP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability |
ONVIF Profile S&G&T, API |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Streaming Method |
Unicast / Multicast |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
User/Host |
20 users |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage |
NAS (Network Attached Storage), Local PC for instant recording, Micro SD card 256GB |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser |
IE, Chrome, Firefox, Safari |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Management Software |
Smart PSS, DSS, DMSS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Phone |
IOS, Android |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications |
CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB,ANSI C63.4- 2014 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Interface |
1 port(BNC, 1.0V[p-p], 75Ω) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS485 |
1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio I/O |
1/1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm I/O |
7/2 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
AC24V/3A(±25%), Hi-PoE |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption |
26W, 42W (Heater on, IR on) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environment |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Conditions |
-40°C ~ 70°C (-40°F ~ +158°F) / Less than 95% RH |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Ingress Protection |
IP67 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Structure |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing |
Metal |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions |
Φ262(mm) x 415.6 (mm) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
8.5kg(18.74lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
13.5kg(29.76lb) |
