Camera |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor |
Panoramic network camera: 1/1.8”CMOS PTZ camera: 1/1.8”CMOS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Resolution |
Panoramic network camera: 4096×1800 PTZ camera: 1920× 1080 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System |
Progressive |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed |
Panoramic network camera: 1/3 s-1/100000 s, manual or auto adjust PTZ Camera: 1/1 s-1/300000 s, manual or auto adjust |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Min. Illumination |
Panoramic network camera: 0.001 Lux@F1.6(Color,30IRE) ;0.0002 Lux@F1.6(B/W,30IRE) PTZ camera: 0.001Lux(colour);0.0002Lux(black);0Lux(IR on) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
S/N Ratio |
Panoramic network camera:>56dB |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illumination Distance |
Panoramic network camera: — PTZ camera: ≥ 220 m (721.78t) (IR on) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator On/Off Control |
Auto/Manual |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator Number |
Panoramic network camera:— PTZ camera: 7 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Type |
Panoramic network camera:Fixed-focal PTZ camera:Motorized vari-focal |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mount Type |
Panoramic network camera:M16 PTZ camera: Core interface |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length |
Panoramic network camera 2.8 mm PTZ camera: 5.62mm~208mm, 37x optical zoom |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Aperture |
Panoramic network camera: F1.6 PTZ camera: F1.4 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Field of View |
Panoramic network camera:Horizontal: 180° Vertical: 80°~85° PTZ camera:Horizontal: Horizontal: 2.61°~59.61° Vertical: 1.48°~34.92° Diagonal: 3°~66.96° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Iris Type |
Panoramic network camera: Fixed aperture PTZ camera: Auto |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance |
Panoramic network camera: 0.2m(0.66ft) PTZ camera:0.1m~1m(0.33ft~3.28ft) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance |
Detect |
Observe |
Reconize |
Identify |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
Panoramic network camera |
29.0m (95.14ft) |
11.6m (38.05ft) |
5.8m (19.02ft) |
2.9m (9.51ft) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
PTZ camera |
1930.7m (6334.31ft) |
772.27m (2533.69ft) |
386.1m (1266.73) |
193.1m (633.53ft) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Event |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IVS |
Intrusion, tripwire |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Codec |
Smart H.264+ Smart H.265+ |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Frame Rate |
Panoramic network camera:Main stream(4096×1800@1~30fps),Sub Stream(1024×452@1~30fps),Third Stream(1920×832@`~30fps) PTZ camera: Main stream(1920×1080@1~30fps),Sub Stream(704×480@1~30fps),Third Stream(1280×720@1~30fps) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Stream Capability |
3 Streams |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution |
Panoramic network camera: 4096 × 1800; 4800 × 1920; 3840 × 1680; 3200 × 1280; 2880 × 1264; 2048 × 900; 1920 × 832; 1600 × 640; 1280 × 560; 1024 × 452 PTZ camera: 1920 × 1080; 1280 × 960; 1280 × 720; 704 × 576; 704 × 480; 352 × 288; 352 × 240 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate Control |
Panoramic network camera: CBR/VBR PTZ camera:CBR/VBR |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Bit Rate |
Panoramic network camera: H.264:112kbps ~25599Kb/S H.265:44kbps ~15494Kb/S PTZ camera: H.264:24kbps ~10752Kb/S H.265:9kbps ~6400Kb/S |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night |
Auto (ICR)/Color/B/W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
BLC |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HLC |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
WDR |
Panoramic network camera:DWDR PTZ camera: WDR (120 dB ) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
White Balance |
Panoramic network camera:Auto/Natural/street lamp/outdoor/manual/regional Custom PTZ camera: Auto/indoor/outdoor/tracking/manual/sodium lamp/natural/street lamp |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gain Control |
Auto/Manual |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction |
3D NR |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motion Detection |
Disable/Enable |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Region of Interest (RoI) |
Yes (4 areas) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Image stabilization(EIS) |
Panoramic network camera: — PTZ camera: Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Illumination |
Panoramic network camera: — PTZ camera: Yes (Adjusted by user.) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Defog |
Panoramic network camera: — PTZ camera: Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Rotation |
0°/180°(PTZ camera) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Privacy masking |
4 areas(Panoramic network camera);24 areas(PTZ camera) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression |
G.711A;G.711Mu;G.726; |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
RJ-45 (10/100/1000 Base-T) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protocol |
IPv4;IPv6;HTTP;HTTPS;TCP; UDP;ARP;RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability |
ONVIF (Profile S/Profile G); CGI; Milestone;Genetec |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
User/Host |
20 (Total bandwidth: 1000 M) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Edge Storage |
FTP;SFTP; Micro SD card (support max. 256 G); NAS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser |
Chrome 42 Firefox 52 IE7;IE8;IE9;IE11 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Management Software |
EVS5XX,EVS7XX,NVR5X-I,NVR4X-4KS2 ,M70,IVSS7X ,DSS Pro&DSS express |
