Camera

Image Sensor

Panoramic camera: 1/1.8”2Megapixel progressive CMOS
PTZ camera: 1/1.8”4Megapixel progressive CMOS

Max. Resolution

Panoramic camera: 4096 (H) × 1800 (V)
PTZ camera: 2560 (H) × 1440 (V)

ROM

Panoramic camera: 4 GB
PTZ camera: 32 GB

RAM

Panoramic camera: 8 GB
PTZ camera: 4 GB

Scanning System

Progressive

Electronic Shutter Speed

Panoramic camera: Auto/Manual 1/3 s–1/100,000 s
PTZ camera: Auto/Manual 1/1 s-1/300,000 s

Min. Illumination

Panoramic network camera:
0.001 Lux (Color); 0.0002 Lux (B/W)
PTZ camera:
0.001 Lux (Color); 0.0001 Lux (B/W); 0 Lux (IR on)

S/N Ratio

Panoramic camera: 56 dB
PTZ camera: 53.6 dB

Illumination Distance

PTZ camera: ≥ 400 m (1312.3 ft) (IR LED)

Illuminator On/Off Control

Auto/Manual

Illuminator Number

PTZ camera: 7 (IR LED)

Lens

Lens Type

Panoramic camera: Fixed-focal
PTZ camera: Motorized vari-focal

Mount Type

Panoramic camera: M12
PTZ camera: Module

Focal Length

Panoramic camera: 5 mm
PTZ camera: 5.6 mm-223 mm, 40x optical zoom

Max. Aperture

Panoramic camera: F2.0
PTZ camera: F1.3

Field of View

Panoramic camera:
Horizontal: 180°
Vertical: 84°
PTZ camera:
Horizontal: 2.27°–61.40°
Vertical: 1.30°–35.99°
Diagonal: 2.62°–68.18°

Iris Type

Panoramic camera: Fixed
PTZ camera: Auto

Close Focus Distance

Panoramic camera: 1.2 m (3.9 ft)
PTZ camera: 0.5 m (1.6 ft)

DORI distance



Detect

Observe

Recognize

Identify

Panoramic camera

53.3 m (174.9 ft)

21.3 m

(69.9 ft)

10.7 m

(35.1 ft)

5.3 m

(17.4 ft)

PTZ camera

2873.1 m (9426.2 ft)

1149.2 m (3770.3 ft)

574.6 m (1885.2 ft)

287.3 m (942.6 ft)

Smart event

IVS

Intrusion, tripwire

Professional, Intelligent

Crowd Distribution Map

Crowd distribution map; global people counting; people counting in area; crowd density abnormality snapshot

Intelligent Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.

Video



Video Compression

H.265; H.264; H.264H; H.264B;

MJPEG (only supported by sub stream)

Smart Codec

Smart H.265+/ Smart H.264+

Video Frame Rate

Panoramic camera:
Main stream: 4096 × 1800 @1–25/30 fps;
sub stream 1: 1920 × 832 @1–25/30 fps;
sub stream 2: 4800 × 1920 @1–25/30 fps
PTZ camera:
Main stream: 2560 × 1440 @1–25/30 fps;
sub stream 1: 704 × 480 @1–25/30 fps;
sub stream 2: 1920 × 1080 @1–25/30 fps

Stream Capability

3 streams

Resolution

Panoramic camera:
4096 × 1800; 4800 × 1920; 3840 × 1680; 3200 × 1280; 2880 × 1264; 2048 × 900; 1920 × 832; 1600 × 640;

1280 × 560; 1024 × 452
PTZ camera:
2560 × 1440; 2048 × 1536; 1920 × 1080; 1280 × 960; 1280 × 720; 704 × 576; 704 × 480; 352 × 288; 352 × 240

Bit Rate Control

Panoramic camera: CBR/VBR
PTZ camera: CBR/VBR

Video Bit Rate

Panoramic camera:
H.264: 256Kbps–25599Kbps

H.265: 196Kbps–15494Kbps
PTZ camera:
H.264: 184 kbps–15104 kbps
H.265: 110 kbps–9216 Kbps

Day/Night

Auto (ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

Panoramic camera:
True WDR:120 dB
PTZ camera: WDR (120 dB )

Scene Self-adaptation (SSA)

Yes

White Balance

Panoramic camera:
Auto/Natural/Street lamp/Outdoor/Manual/Regional custom
PTZ camera:
Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural/Street lamp

Gain Control

Auto/Manual

Noise Reduction

3D NR

Motion Detection

OFF/ON (4 areas)

Region of Interest (RoI)

Panoramic camera: Yes (4 areas)
PTZ camera: Yes (4 areas)

Electronic Image Stabilization (EIS)

PTZ camera: Yes

Smart Illumination

PTZ camera: Yes

Defog

PTZ camera: Yes

Privacy Masking

Panoramic camera: 4 areas
PTZ camera: 8 areas

Audio

Audio Compression

G.711A; G.711Mu; G.726

Alarm

Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection and external alarm.

Network

SDK and API

Yes

Network

RJ-45 (10/100/1000 Base-T)

Protocol

HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE;IPv4/v6; SNMP; QoS; UPnP; NTP

Cyber Security

Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade

Interoperability

ONVIF (Profile G/T/S); CGI

User/Host

20 (Total bandwidth: 600 M)

Storage

FTP; SFTP; Micro SD card (support max. 512 G);NAS

Browser

IE: IE7 and earlier
Chrome: 42 and earlier
Firefox: 52 and earlier
Safari: 11 and earlier

Management Software

EVS; NVR; M70; DSS; Milestone; Genetec

Mobile Phone

IOS; Android

PTZ Dome

Pan Range

Pan: 0° to 360° endless
Tilt: –12° to 90°, auto flip 180

Manual Control Speed

Pan: 0.1°/s–240°/s
Tilt: 0.1°/s–100°/s

Remote Lens Reset

Yes

Remote PTZ Reset

Yes

Preset

300

Tour

8 (up to 32 presets per tour)

Pattern

5 patterns

Scan

5 auto scans

Power-off Memory

Yes

Idle Motion

Preset/Pattern/Tour/Scan

Time Task

Yes

3D Positioning

Yes

PTZ Limit

Yes

Position Display

Yes

Information Display

Yes

Time Display

Yes

Others

Auto-calibration

Certifications

Certification

CE-LVD:EN62368-1

CE-EMC:Electromagnetic Compatibility Directive 2014/30/EU

FCC:47 CFR FCC Part 15, Subpart B

UL/CUL:UL60950-1 CAN/CSA C22.2 No.60950-1-07

Port

Audio Input

2 channels (terminal)

Audio Output

2 channels (terminal)

Alarm Input

7 channels in: 5mA 3V–5V DC

Alarm Output

3 channels out: 300mA 12V DC

Power

Power Supply

36V DC
