Platform |
EVS, NVR, M70, DSS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification |
CE-LVD: EN60950-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS-485 port |
One (Bit rate: 1200 bps-115200 bps) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio input |
2 channels (connecting terminal) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio output |
2 channels (connecting terminal) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm input |
7 channels (Wet contact, and it supports potential 3V–5V and max current 0.5A.) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm output |
3 channels (Wet contact, and it supports max potential 30V DC, 1 A/max potential 50V AC, current 0.5 A.) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Analog output |
1 channel CVBS BNC port |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power supply |
220V AC DC36V |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power consumption |
< 84.4W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environment |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating temperature |
-40°C to +70°C (-40°F to +158°F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating humidity |
≤95% |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage temperature |
-40°C to +70°C (-40°F to +158°F)/Less than 95% RH |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protection grade |
IP66 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Structure |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Enclosure |
Metal + Plastic |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions |
Φ383 mm × 389.8 mm (Φ1256.56 ft × 1279.8 ft) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net weight |
14.7 kg (32.41 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross weight |
19.8 kg (43.65 lb) |
