Camera

Image Sensor

1/2.7”5Megapixel progressive CMOS

Max. Resolution

2592 (H) × 1944 (V)

ROM

32 GB

RAM

4 GB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

0.005 Lux@F1.7(Color,30IRE)

0.0005 Lux@F1.7(B/W,30IRE)

0 lux (Illuminator on)

S/N Ratio

> 56 dB

Illumination Distance

30 m (98.4 ft) (IR LED)

Illuminator On/Off Control

Auto/Manual

Illuminator Number

8 (IR LED)

Pan/Tilt/Rotation Range

Pan: 0°–360°
Tilt: 0°–80°
Rotation: 0°–355°

Lens

Lens Type

Motorized vari-focal

Mount Type

φ14

Focal Length

2.8 mm–12 mm

Max. Aperture

F1.7

Field of View

Horizontal: 100°–36°
Vertical: 74°–27°
Diagonal: 133°–45°

Iris Type

Fixed

Close Focus Distance

0.8 m (2.6 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

W

66 m

(216.5 ft)

26.4 m

(86.6 ft)

13.2 m

(43.3 ft)

6.6 m

(21.7ft)

T

140.4 m (460.6 ft)

56.1 m

(184.1 ft)

28 m

(91.9 ft)

14 m

(45.9 ft)

Smart Event

IVS

Abandoned object; missing object

Professional, intelligent

IVS (Perimeter Protection)

Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection

Face Detection

Face detection; track; optimization; snapshot; report high quality picture; face enhancement; face exposure; face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear), mask, beard; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting

Intelligent Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)

Smart Codec

Smart H.265+/Smart H.264+

Video Frame Rate

Single Stream:
Main stream: 5MP (1–25/30 fps)
Sub stream: D1 (1–25/30 fps)
Third stream: 2MP (1–25/30 fps)
FlexStream:
Main stream: 2MP (1–25/30 fps)
Sub stream: D1 (1–25/30 fps)
Third stream: 8MP (1–25/30 fps)

Stream Capability

3 streams

Resolution

Single Stream: 5M(2592×1944); 4M(2688×1520);

3M(2048×1536);2M(1920×1080);720P(1280×720);

D1(704× 576/704×480);CIF(352×288/352×240)

FlexStream:8M(3296×2472);5M(2592×1944);

2M(1600×1200);1.3M(1280×960);

D1(704× 576/704×480);CIF(352×288/352×240)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 3 kbps–19456 kbps
H.265: 3 kbps–19456 kbps

Day/Night

Auto (ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

4 × 120 dB

White Balance

Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control

Auto/Manual

Noise Reduction

3D NR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest (RoI)

Yes (4 areas)

Smart Illumination

Yes

Image Rotation

0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)

Mirror

Yes

Privacy Masking

4 areas

Audio

Audio Compression

G.711a; G.711Mu; PCM; G.726; G.723

Alarm

Alarm Event

No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; defocus detection; external alarm; face detection; safety exception; voltage detection

Network

Network

RJ-45 (10/100/1000 Base-T)

SDK and API

Yes

Cyber Security

Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade

Protocol

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP

Interoperability

ONVIF(Profile S/Profile G/Profile T); CGI; Milestone; Genetec; RTMP; P2P

Storage

FTP; SFTP; Micro SD card (support max. 256 G); NAS

Browser

IE: IE9 and later
Chrome: 41.0 and later
No-plug version: Safari and edge

Management Software

Smart PSS; DSS

Mobile Phone

IOS; Android

Certification

Certification

CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Port

RS-485

1 (baud rate range: 1200 bps–115200 bps)

Audio Input

1 channel (RCA port)

Audio Output

1 channel (RCA port)

Alarm Input

3 channel in: 5mA 3V–5V DC

Alarm Output

2 channel out: 300mA 12V DC

Power

Power Supply

12V DC/POE( 802.3at )

Power Consumption

Basic power consumption: 8.1W (12V DC); 9W (PoE)
Max. power consumption (ICR + IR intensity): 21.5W (12V DC); 22.2W (POE+)

Environment

Operating Conditions

–30°C to +60°C (–22°F to +140°F)/Less than 95% RH

Storage Conditions

–30°C to +60°C (–22°F to +140°F)

Protection Grade

IP67; IK10

Structure

Casing

Metal + Plastic

Dimensions

286.1 mm × 111.3 mm (11.3" × 4.4")

Net Weight

2.75 kg (8.9 lb)

Gross Weight

4.5 kg (11.0 lb)
