Camera

Image Sensor

Four 1/2.8” 2Megapixel progressive scan CMOS

Effective Pixels

1920(H)x1080(V)

RAM/ROM

1024MB/128MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3(4)~1/100000s

Minimum Illumination

0.006Lux/F1.85( Color,1/3s,30IRE)

0.05Lux/1.85( Color,1/30s,30IRE)

0Lux/F1.85(IR on)

IR Distance

N/A

IR On/Off Control

N/A

IR LEDs

N/A

Lens

Lens Type

Fixed

Mount Type

Board-in

Focal Length

2.8mm;3.6mm

Max. Aperture

F1.85

Angle of View

H: 99° V:56°; V:87° ~47°

Aperture Type

Fixed

Close Focus Distance

0.5m(1.64ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8mm

37m(121ft)

15m(49ft)

8m(26ft)

4m(13ft)

3.6mm

53m(174ft)

21m(69ft)

11m(36ft)

5m(16ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

Pan:0˚~360˚; Tilt:0˚~80˚; Rotation:0˚~355˚

Intelligence

Event Trigger

Motion detection, Video tampering, Scene changing,

Network disconnection, Ip address conflict, Illegal

access, Storage anomaly

IVS

Tripwire, Intrusion

Video

Compression

H.265/H.264/H.264B/H.264H/MJPEG(sub stream)

Smart Codec

Support H.265+/H.264+

Streaming Capability

2 Streams

Resolution

1080P(1920×1080)/1.3M(1280x960)/ 720P(1280x720)/D1(704×576/704x480)/ CIF(352×288/352×240)

Frame Rate

Main Stream: 1080P(1~25fps)

Sub Stream: D1(1~25fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.264: 32~8192Kbps

H.265: 19~4608Kbps

Day/Night

Electronic

BLC Mode

BLC / HLC / DWDR

White Balance

Auto/Manual

Gain Control

Auto/Manual

Construction

Casing

Metal

Dimensions

71.5 mm×Φ159.1 mm

Net Weight

0.85kg (1.87lb)

Gross Weight

1.05kg (2.31lb)

Noise Reduction

3D DNR

Motion Detection

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Electronic Image Stabilization (EIS)

N/A

Smart IR

N/A

Defog

N/A

Digital Zoom

16x

Flip

0°/90°/180°/270°

Mirror

Off / On

Privacy Masking

Off / On (4 Area, Rectangle)

Audio

Compression

G.711a/ G.711Mu/ AAC/ G.726/ MP2L2/ G.722

Network

Ethernet

RJ-45 (100/1000Base-T)

Protocol

HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; SNMP; QoS; UPnP; NTP; Bonjour; HTTPS; 802.1x; NAS

Interoperability

ONVIF Profile S&G, API, CGI

Streaming Method

Unicast / Multicast

Max. User Access

10 Users /20 Users

Edge Storage

NAS

Local PC for instant recording

Mirco SD card 256GB

Web Viewer

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS, DMSS

Smart Phone

IOS, Android

Certifications

Certifications

CE-LVD: EN60950-1

CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

FCC: 47 CFR FCC Part 15, Subpart B

Interface

Video Interface

N/A

Audio Interface

1/1 channel In/Out

RS485

N/A

Alarm

1 channel In: 500mA 5VDC

1 channel Out: 1A 30VDC

Electrical

Power Supply

DC12V, PoE(802.3af)(Class 0)

Power Consumption

DC 12V: 5.3W 6.2W(H.265+DWDR+Audio+Alarm)

PoE: 6.4W 7.4W(H.265+DWDR+Audio+Alarm)

Environmental

Operating Conditions

-40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Stroage Conditions

-30° C ~ +70° C (-22° F ~ +158° F) / Less than 95% RH

Ingress Protection

IP67

Vandal Resistance

IK10
