Camera

Image Sensor

1/2.8 2Megapixel progressive scan CMOS

Effective Pixels

1920(H)x1080(V)

RAM/ROM

1024MB/128MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

0.003Lux/F2.0 ( Color,1/3s,30IRE)

0.02Lux/F2.0 ( Color,1/30s,30IRE)

0Lux/F2.0 (IR on)

S/N Ratio

More than 45dB

IR Distance

Distance up to 50m(164ft)

IR On/Off Control

Auto/Manual

IR LEDs

8

Lens

Lens Type

Fixed

Mount Type

Board-in

Focal Length

2.8mm(3.6mm;6mm;8mm;12mm)

Max. Aperture

F2.0

Angle of View

H: 110 ˚ (89.5°)(52.8°)(39.7°)(25.7°)

V: 60˚ (50˚)( 30°)(22°)(14.4°)

Optical Zoom

N/A

Focus Control

Fixed

Close Focus Distance

0.5m(0.9m)(2.1m)(3.5m)(8.5m)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8mm

39m(128ft)

15m(49ft)

8m(26ft)

4m(13ft)

3.6mm

55m(180ft)

22m(72ft)

11m(36ft)

5.5m(18ft)

6mm

83m(272ft)

33m(108ft)

17m(56ft)

8m(26ft)

8mm

107m(351ft)

43m(141ft)

21m(69ft)

11(36ft)

12mm

172m(564ft)

69m(226ft)

3m(10ft)

17m(55.8ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

Pan:-30˚~30˚; Tilt:0˚~80˚; Rotation:0˚~360˚

Artificial Intelligence

People Counting

Support Line crossing/Region people counting

Face Caputure

Support face image caputure



Face Attributes

Support 4 kinds of face attributes extraction: Age, Gender, Expression(Jolly, Calm, Surprise, Sad, Rage), Glasses

Video

Compression

H.265/H.264H/H.264/H.264B/MJPEG(Sub Stream

Smart Codec

Support H.265+/H.264+

Streaming Capability

3 Streams

Resolution

1080P(1920×1080)/ 1.3M(1280x960)/ 720P(1280x720)/ D1(704×576/704x480)/ CIF(352×288/352×240)

Frame Rate

Main Stream: 1080P(1~25/30fps)

Sub Stream: D1 (1 ~ 25/30fps)

Sub Stream 2: 1080P(1~25/30fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.264H:32Kbps ~ 15104Kbps

H.6Kbps~ 15104Kbps

Day/Night

Auto(ICR) / Color / B/W

BLC Mode

BLC / HLC / WDR(120dB)

White Balance

Auto/Manual

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Electronic Image Stabilization (EIS)

N/A

Smart IR

Support

Defog

Support

Digital Zoom

16x

Flip

0°/90°/180°/270°

Mirror

Off / On

Privacy Masking

Off / On (4 Area, Rectangle)

Audio

Compression

G.711a/G.726/G.711Mu/AAC

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

HTTP;TCP;ARP;RTSP;RTP;UDP;RTCP;SMTP;FTP;DHC P;DNS;DDNS;PPPOE;IPv4/v6;SNMP;QoS;UPnP;NTP

Interoperability

ONVIF;CGI;Milstone;Genetec

Streaming Method

Unicast / Multicast

Max. User Access

10Users/20 Users

Edge Storage

NAS

Local PC for instant recording

Web Viewer

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS, DMSS

Smart Phone

IOS, Android

Certifications

Certifications

CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

EN50155(optional)

Interface

Video Interface

N/A

Audio Interface

Built-in Mic

RS485

N/A

Alarm

N/A

Electrical

Power Supply

DC12V, PoE (IEEE 802.3af)(Class 0)

Power Consumption

DC 12V: 3.6W 5.4W(IR on)

PoE: 4.2W 6.2W(IR on)

Environmental

Operating Conditions

-40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Storage Conditions

-40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Ingress Protection

IP67

Vandal Resistance

IK10

Construction

Casing

Metal
