Interface

Video Interface

1 port (BNC, 1Vp-p, 75Ω )

Audio Interface

1/1 channel In/Out, Built-in MIC

RS485

1 port

Alarm

2 channel In: 5mA 5V DC
1 channel Out: 300mA 12V DC

Power Out

165mA 12V DC

Electrical

Power Supply

DC 12V (±25%), AC 24V (±25%), PoE (802.3af)

(Class 0)

Power Consumption

<9.5W

Environmental

Operating Conditions

-30° C to +60° C (-22° F to +140° F)/Less than 95% RH

Storage Conditions

-30° C to +60° C (-22° F to +140° F)

Ingress Protection

N/A

Vandal Resistance

N/A

Construction

Casing

Metal

Dimensions

135.4 mm × 74.4 mm × 65.5 mm(5.33” × 2.93” × 2.58”)

Net Weight

0.53 kg (1.17 lb)

Gross Weight

0.62 kg (1.37 lb)
